Title 2024 STEELMASTER AML-3 - 1550MM HVAC DUCT LINE 1550mm Wide
Make STEELMASTER
Sale Price 88850 $97,735
Listing Type New
Stock Number 20-0618
RefCode TA961956

Description

Description
Our Duct production line III comprises of a twin decoiler, leveller grooving unit, V and notching unit, cutting unit, bending unit composition. The standard configuration the V and notching unit make for TDF flange duct, thereinto the notching unit also can be used to produce TDC flange. Bending unit can be made with the Pittsburgh match the right angle, also can be sheet metal bending into a "" or "L" type. Greatly improve the utilization of the plate, reduce labour intensity and reduce labour.
The production line electrical control part adopts full servo control; the control system has a closed-loop feedback system, Accuracy and stability were obvious improved. The maximum operating speed of 16 m / min.
Length tolerance is ±0.5mm; diagonal tolerance is ± 0.8mm. The system can meet the each shift8 hours production capacity of 1000m2 duct.

Technical Snap Shot.
Up to 1550mm wide material
Panasonic Servo PLC Control
Levelling, Notching, Shearing & Folding
Thickness: 0.4-1.0mm
Shearing tolerance of ±0.5mm
Hydraulic folding tolerance of ±0.5mm
0-16m/min feeding speed, fast acting back gauge
Dimensions: 9800mm x 1800mm x 1400mm x 4800Kg

Largest EX STOCK range of HVAC & Ductwork Fabrication Direct to The Industry
Steelmaster Industrial offer the largest EX STOCK range of HVAC & Ductwork Fabrication Direct to The Industry
Our products include, complete HVAC auto metalworking processing lines, Lockseamer, TDC & TDF roll formers, TDF & TDC auto corner inserters, HVAC seam closers, Jenny & Swage Machines, curving rollers, TDF folders, Metalworking Guillotines, Metalworking Panbrake Folders, CNC HVAC Plasma cutting machines, HVAC Collar roller & Edge Notcher, Rib & Bead Rolling Machines, Snap Lock Machines and so much more
All our HVAC metalworking machines are pre commissioned prior to delivery and we offer qualified technicians for onsite set up and training if required.
We can also offer support for leading brands as Lockformer, Pittsburgh, Vulcan CNC Plasma, RAS HVAC Machinery and more.

If you cant find what youre looking for call us on or look online www.steelmastermachinery.com.au

Servicing the Industrial Metalworking Industry since 1997

We have many more items available than listed here.

Asset offer a wide variety of metalworking machinery, spare parts and accessories to suit our range
Industries service range from Engineering, Metalworking Fabrication & Sheetmetal Shops Australia Wide.
Also offering national delivery on metalworking bandsaw & cold saw blades, Punch & Shear Tooling, Pressbrake Tooling, Industrial Conveyors and much more.

We can also offer experienced service technicians in house or onsite to assist Please contact us for further information.

Visit our website, or call us with your requirements

Tell us what you are after, chances are we have it already.

For More information on our machine, go to or contact a Steelmaster industrial Rep

MAKE YOUR NEXT PURCHASE AN "ASSET" TO YOUR COMPANY!
Please contact us for more information.

## STEELMASTER INDUSTRIAL OFFER A COMPLETE RANGE OF NEW & USED METALWORKING MACHINERY FOR SALE AUSTRALIA WIDE ##
