HAFCO HMA-386

HMA-386 NT30 Horizontal Milling Attachment Suits ??86mm Quill HAFCO-METALMASTER HMA-386 NT30 Horizontal Milling Attachment Suits ??86mm Quill CALL NOW AND DO A DEAL! ADD THIS ASSET TO YOUR WORKSHOP WE OFFER MACHINERY SOLUTIONS AT AFFORDABLE PRICES. Order Code: M213 Manufactured in Taiwan Used on vertical milling machine where horizontal work is required. Designed to simplify right angle work without the need for special tooling or complex fixtures. Note! If using with an air powered drawbar the drive motor of the drawbar needs to be removed as the quill is lowered so that the horizontal attachment can be secured. As the quill is lowered the air drawbar is dis-engaged and cannot be used. For this application use a standard drawbar. Features: Arbor support suits dovetail widths of 140-170mm Supplied in deluxe wooden case Arbor ??1`` x 12`` in length Specifications: ORDER CODE: M213 MODEL: HMA-386 Taper: NT30 Quill Diameter (mm): ??86 Maximum Speed (rpm): 2000 A (deg): 50?? B (mm): 140 - 170 C (mm): 175 D (mm): 160 E (mm): 270 F (mm): 230 G (mm): 45 Nett Weight (kg): 30 To Purchase Online Please Visit The Machineryhouse Website & Search For 'M213' Visit us in-store at: Sydney - Unit 1, 2 Windsor Road, Northmead NSW 2152 Melbourne - 4 Abbotts Road, Dandenong South VIC 3175 Brisbane - 625 Boundary Rd, Coopers Plains QLD 4108 Perth - 11 Valentine Street, Kewdale WA 6105 Adelaide - Unit 11/20 Cheltenham Parade, Woodville SA 5011
