Title HAFCO HM51B
Make HAFCO
Sale Price $7,095
Listing Type New
Stock Number M577
RefCode TA964471

Description

Features:
3 Axis digital readout system
Mill head tilts to ±90º left to right
300mm horizontally sliding and rotating ram
NT30 vertical spindle is hardened and ground
Precision-ground dovetail slide-ways and table
Precision milling table incorporating machined T-slots
Rear concertina slide-way cover
Forward and reverse on/off switch
Fine hand wheel operated quill feed
Swarf & splash tray
Spindle lock for quill
Metric dial graduations 0.02mm for X Y & Z-Axis
Vertical quill hand-wheel dial graduations 0.05mm
All slides utilise dovetail construction for maximum rigidity

  • Note: X & Y travels maybe reduced due to digital readout scales and safety stops
  • Note: Optional Y & Z power feeds require additional parts & fitting (not included)

Includes:
- 3 Axis digital readout system
- X-Axis power feed
- Safety cutter guard
- Swarf tray
- Coolant system
- Halogen lamp
- Drill chuck & arbor
- 2 & 3MT adaptors
- Boring bar arbor



Specifications:
ORDER CODE: M576
MODEL: HM-51
Digital Readout: 3-Axis Digital Readout
Type: Vertical
Table Size (mm): 1000 x 240
Spindle Taper - Vertical: NT30
Longitudinal Travel (X-Axis) (mm): 600*
Cross Travel (Y-Axis) (mm): 220*
Vertical Travel (Z-Axis) (mm): 310
Type of Slides: Dovetail
Ram Travel (mm): 350
Spindle to Table (mm): 415
Spindle Travel / Diameter (mm): 120 / 90
Throat Depth (max.) (mm): 550
Tilting Head (Left ~ Right): ±90º
Tilting Head (Forward ~ Back): Fixed
Drilling Capacity (mm): 30
End Milling Capacity (mm): 25
Face Milling Capacity (mm): 80
Power Feed - Quill (mm/rev): Manual
Power Feed - Longitudinal (X-Axis) (mm/min): 20 - 2000
Power Feed - Cross (Y-Axis) (mm/min): Optional *
Power Feed - Vertical (Z-Axis) (mm/min): Optional *
Table T-Slot Size (inch / mm): 14
Work Table Load Capacity (kg): 175
Spindle Speeds Vertical (No./ rpm): 9 (220 - 2400)
Motor Power - Vertical (kW / hp): 1.5 / 2
Voltage / Amperage (V / amp): 240 / 10
Shipping Dimensions (L x W x H) (cm): 134 x 114 x 222
Nett Weight (kg): 850
